Authorization Code + PKCE

Implement the recommended browser and mobile app flow for TokenIDP.

Audience: Developers, CTOs

Read this guide when your client cannot safely keep a client secret, such as a SPA or mobile app.

Prerequisites

  • Public Application registration
  • Exact redirect URI registered in TokenIDP
  • PKCE code verifier and S256 code challenge support in the client
OAuth Authorization Code with PKCE flow

Step-by-Step Sequence

  1. The client creates a high-entropy code verifier.
  2. The client derives an S256 code challenge.
  3. The browser is redirected to /authorize.
  4. The user authenticates and grants consent if required.
  5. TokenIDP redirects back with an authorization code.
  6. The client posts the code and code_verifier to /token.
  7. TokenIDP verifies the PKCE binding and returns tokens.

Working Example

Example Authorization Request

GET /authorize?client_id=tokenidp-react-dev&redirect_uri=http%3A%2F%2Flocalhost%3A5173%2Fcallback&response_type=code&scope=openid%20profile%20email%20offline_access%20api.read&state=af0ifjsldkj&code_challenge=E9Melhoa2OwvFrEMTJguCHaoeK1t8URWbuGJSstw-cM&code_challenge_method=S256 HTTP/1.1
Host: localhost:5001

Example Token Request

curl -X POST https://localhost:5001/token \
  -H "Content-Type: application/json" \
  -d '{
    "grantType": "authorization_code",
    "clientId": "tokenidp-react-dev",
    "code": "SplxlOBeZQQYbYS6WxSbIA",
    "redirectUri": "http://localhost:5173/callback",
    "codeVerifier": "dBjftJeZ4CVP-mB92K27uhbUJU1p1r_wW1gFWFOEjXk"
  }'

Example Response

{
  "isSuccess": true,
  "data": {
    "accessToken": "eyJhbGciOiJSUzI1NiIsImtpZCI6IjIwMjYtMDMtMTYifQ...",
    "refreshToken": "8d2a5d18-b8cb-44b9-9d5c-bccaf4877baf",
    "idToken": "eyJhbGciOiJSUzI1NiIsImtpZCI6IjIwMjYtMDMtMTYifQ...",
    "tokenType": "Bearer",
    "expiresIn": 3600
  }
}

When to Use

  • SPAs
  • Native mobile applications
  • Desktop applications

When Not to Use

  • Server-to-server integrations that can safely use client authentication
  • Legacy clients that cannot preserve PKCE state correctly

Security Notes

  • TokenIDP requires response_type=code and PKCE parameters on /authorize.
  • Use exact redirect URI matching.
  • Keep state unpredictable and validate it on return.
  • Prefer short-lived Access Tokens and rotated Refresh Tokens.

Common Pitfalls

  • Sending code_challenge_method=plain when the client expects S256.
  • Exchanging the code with a different redirect URI than the one used on /authorize.
  • Logging the raw authorization code in browser telemetry.

Troubleshooting Tips

  • If /authorize returns Missing PKCE parameters., verify both code_challenge and code_challenge_method.
  • If /token rejects the code, confirm the code verifier belongs to the same browser session and login attempt.
